Controller
Flowchart
Technical Parameters
| Model | Smart-RRO24 | |||
| Pure water output* | 1-stage RO water 45 L/h, 2-stage RO water 24 L/h | |||
| RO water specifications | ||||
| 1-stage RO water | Ion rejection rate 98%–99% (new membrane), organic rejection rate > 99% (MW > 200 Daltons), particle/bacteria rejection rate > 99% | |||
| 2-stage RO water | Ion rejection rate > 99% (new membrane), conductivity ≤ 5 µS/cm, organic/particle/bacteria rejection rate > 99%; conforms to Chinese standard for Type III water quality (RRO/RS only) | |||
| Raw water requirements | Municipal drinking (tap) water; temperature: 5–35 °C; pressure: 1.0–4.0 bar | |||
| Dimensions/Weight | 410×220×420 mm (L×W×H)/approx. 18 kg | |||
| Electrical requirements | 100–240 V, 50/60 Hz | |||
| Power | 72 W | |||
| System configuration | Main unit + built-in 1.8L pressure tank + accessory kit | |||
* The value is affected by water temperature, feed water quality, and total contaminant load.
