Controller
Flowchart
Technical Parameters
| Model | Pilot-Q45/60/90/120/180 | Pilot-Q45/60/90/120/180UT |
| Pure water output* | 45/60/90/120/180 L/h | |
| Max. flow rate | 3.0 L/min | |
| DI water specifications | ||
| Resistivity (25 ℃) | 13–17.5 MΩ.cm | |
| Heavy metal ions | <0.1 ppbd> | |
| Bacteria | N/A | <0.01 cfu/>l |
| Particles (> 0.2 μm) | N/A | <1/>l |
| RO water specifications | ||
| Ion rejection rate | 98%–99% (with new RO membrane) | |
| Organic rejection rate | > 99% (MW > 200 Daltons) | |
| Particle/bacteria rejection rate | > 99% | |
| Raw water requirements | Municipal drinking (tap) water; temperature: 5–35 °C; pressure: 1.0–4.0 bar | |
| Dimensions/Weight | 640×580×1130 (L×W×H)/approx. 70 kg | |
| Electrical requirements | 100–240 V, 50/60 Hz | |
| Power | 120–300 W | |
| System configuration | Main unit + 2 built-in 15L pressure tanks + 13L high-capacity patented purification cartridge + accessory kit | |
* The value is affected by water temperature, feed water quality, and total contaminant load.
